לוח אם PRIME Z890-P

נפח זיכרון    256GB
סוג זכרון    DDR5
נפח אחסון    4 חריצי M.2 (PCIe 5.0 ו-4.0)
סוג האחסון    M.2
תושבת מעבד (Socket)    1851
ערכת שבבים    Intel Z890
ממשק    Wi-Fi 7, Bluetooth 5.4, 4x USB 3.0, 4x USB 2.0, 1x USB-C 3.2, 1x HDMI 2.1, 1x RJ-45 2.5Gb LAN
מפרט
4-Pin ATX12V: 1

Graphics: iGPU

Miscellaneous-Interfaces: 6x SATA 6Gb/s (Z890)

fan 4-Pin: 4

Lighting: not available

3.5mm jack: 3

max. 3A: 1

HDMI 2.1: 1

MOSFETs-VCORE: 10x 80A DrMOS

USB 2.0 header 9-Pin: 2

TPM-Header: 1

USB-A 2.0: 2

24-Pin ATX: 1

RAM-operating-frequency native: DDR5-5600 UDIMM/DDR5-6400 CUDIMM

max. 3A): 1

PCIe-Slots: 1x PCIe 5.0 x16, 3x PCIe 4.0 x16 (1x x4, 2x x1)

buttons/Switches: USB BIOS Flashback (external)

chipset: Intel Z890

RAID-level: 0/1/5/10

USB 3.0 Header 20-Pin: 1

MOSFETs-VDDMISC/VCCSA/VCCAUX: 2x 80A DrMOS

USB-C 3.2 with DisplayPort 1.4: 1

Special-features: audio solid capacitors, I/O-shield integrated, white Build compatible (PCB primary black), 1x M.2-passive cooler

ASUS TBHEADER: 1

S/PDIF-Header: 1

Chassis Intrusion-Header: 1

USB-A 3.0: 4

CPU fan 4-Pin: 2

RAM-operating-frequency OC: DDR5-7600

AIO-pump 4-Pin: 1

RJ-45 2.5Gb LAN: 1

8-Pin EPS12V: 1

Socket: Intel 1851 (LGA1851)

4-Pin RGB: 1

antenna connector Quick Connect: 2

3-Pin ARGB: 3

ECC-support: no

ASUS Gen2): 1

M2-Slots: 1x M.2/M-Key (PCIe 5.0 x4, 2280), 2x M.2/M-Key (PCIe 4.0 x4, 2280), 1x M.2/E-Key (2230, occupied with WiFi BT module)

Audio: Realtek ALC897

NAME: ASUS Prime Z890M-Plus WIFI

Wireless: Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2), Bluetooth 5.4

USB-C 3.0 Key-A Header: 1

VRM-Design: 10 1 2 1, 11 virtual CPU-phases ([5 5]1), 6 real CPU-phases (5 1)

DisplayPort 1.4: 1

MOSFETs-SOC/VCCGT: 1x 80A DrMOS

USB 3.0): 2

MOSFETs-VNNAON: 1x 80A DrMOS

CPU-Compatibility: Core Ultra 200, CPU-compatibility list

BIOS: 1x 32MB (256Mb)

USB 2.0): 4

iGPU): 1

SKU: 90MB1J80-M0EAY0

shape-factor: ֲµATX

RAM-Slots: 4x DDR5 DIMM, Dual Channel, max. 256GB (UDIMM), 256GB (CUDIMM)

USB-A 3.1: 1

serial-Header: 1

ספק יבואן    יבואן רשמי
סוג האחריות    שלוש שנים
